Logitrans Electric Stacker, Model Selfs Mini 1002, 2013, s/n 134E24112066, Capacity 1,000kgs, Lift height 890mm, Load centre 575mm, Motor 700W, Hydraulic motor 1,200W, Battery 24V, Battery weight 130kgs, Overall weight 314kgs
Swing over bed 400mm.Swing over cross slide 246mm. Height of centres 195mm. Distance between centres 1270mm. Spindle nose D1 – 6 Camlock. Taper in spindle nose bush No 4 MT. Spindle bore 54mm. Spindle speeds 14 – 2500 rpm (Inf.var.) Maximum spi...
MANDELLI
07422
CNC CNM PLASMA
STROKES:
Axis X mm -750 +2600
Axis U mm +750 +2600
Axis Y mm 2000
Axis Z mm 1500
ROTARY TABLE:
Dimensions mm 1100x1250
Degrees 1/1000°
Positioning accuraracy sec. +/- 6
Maxload Kg 4000
T-slots n.xmm 8x18
T-slot distance...
