MORI SEIKI
08864
HORIZONTAL 8 PALLET
STROKES:
Axis X stroke mm 900
Axis Y stroke mm 800
Axis Z stroke mm 980
Distance between table / spindle center line mm 100-900
Distance between table surface / spindle end surface mm 100-1080
TABLE:
Table work su...
Table size 600mm × 500 mm. Max workpiece size 730mm × 450 mm. Max capacity on table 500 kg. X/Y/Z travels 850mm/550/510mm. B axis (table tilt) 210 º (-120º +90º). C axis (table rotation) 360º. Min/Max distance spindle nose to table top 70...
