TOPPER
08196
CAMBIO PALLET
CNC FANUC O-M
Axis X longitudinal travel mm 760
Axis Y cross travel mm 530
Axis Z vertical travel mm 530
Table dimensions mm 700x500
Spindle taper NT NO. 40
Spindle speed rpm 50-5000
Spindle motor power kW 15 (50% ED)
Tool ...
Pressure total: 40 ton
Daylight: 740 mm
Table surface area : 670 x 570 mm
Slide area: 670 x 570 mm
Ejector Force: 30 kN max.
capacity of swivelling ram plate: 10 kN
Die Weight on table max.: 20 kN
Oil volume: 120 l
Required power: ...
Main motor power: 5,5Kw.Working capacity L Profile: 90 x 90 x 11mm.Working capacity Round Profile: 120mm.Total weight: 2.100kg.Notes: COMPLETE WITH:- PIPE DIES
