W. PAUL MÜLLER EXP 1OO SF-HK

MACHINE INFORMATION AND SPECIFICATION

Subcategory:

Eccentric C-Frame Presses

Manufacturer:

W. Paul Muller

Model:

W. PAUL MÜLLER EXP 1OO SF-HK

Condition:

Used

YOM:

Control:

Price:

Seller:

Pressen Haas

Country:

Germany

DESCRIPTION

stock no.: 1131-0295
Machine type: Eccentric C-Frame press
Manufacturer: W. Paul Müller
Type: ExP 1OO SF-HK
Serial no.: A 03002 - 01
YOM: 2003
Delivery time: immediately
Location: 72479 Strassberg
Technical details:
Capacity: 100 ton
Ram stroke: 10 - 140 mm
Slide adjustment: 120 mm
Shut height (stroke down,
adjustment up): 440mm
Number of strokes: 70 - 140 s.p.m.
Throat depth: 320 mm
Table surface area : 900 x 580 mm
Slide area: 450 x 290 mm
Hole in table: 410 x 290 mm
T-Slots (DIN 650): 22 mm
Tool Clamping Hole Ram: M 20
Work capacity: 2.510 - 3.390 Nm
Required power: 9,5 kW
Dimensions L x W x H: 1.500 x 1.900 x 2.700 mm
Weight of machine approx.: 5 ton
Standard configuration:
hydraulic Ortlinghaus-Clutch
Ortlinghaus hydraulik unit
manual stroke adjustment
Herion overload protection
Description: New SIEMENS S7 PLC in 2019.
Condition is very good.
