REQUEST PRICE

Trumpf - Trumatic L 4050 - 5 kW

MACHINE INFORMATION AND SPECIFICATION

Subcategory:

Laser Cutting

Manufacturer:

TRUMPF

Model:

Trumpf - Trumatic L 4050 - 5 kW

Condition:

Used

YOM:

Control:

Price:

Seller:

PTF-GmbH

Country:

Germany

DESCRIPTION

Working hours laser on: 73521 h
Working hours beam on: 31732 h
Laser power: 5000 Watt
Control: Siemens 840 D
Working range laser: 4000 x 2000 x 115 mm
Max. steel: 25 mm
Max. stainless steel: 20 mm
Max. aluminium: 12 mm
Length: 13000 mm
Width: 5400 mm
Height: 2400 mm
Machine weight: 14000 kg
Electrical connected load: 105 kVA
Standard configuration:
Closed machine frame with integrated laser unit Laser unit
CO2 laser TLF radio-frequency excited mirror telescope, chiller
Automatic pallet change
HI-LAS high pressure cutting
Plasma sensor system
High-speed processing with SprintLas
ContourLas for producing small holes
Microweld
Programmable cutting gas pressure setting
Laser cutting head with 9” lens
Laser cutting head with 7.5” lens
Cutting head quick-change device
Programmable power cycles
Positioning laser diode
Automatic sheet edge detection
Automatic focus setting AutoLas Plus
Oil spray device for reliable thick plate machining
Laser logbook function
Automatic shutdown
Work area lighting
Sinumerik 840D control:
Open PC-based control system, easy to use, Online help, diagnostic functions, maintenance logbook, technology data, Teleservice, 3.5" disk drive, BNC-/RJ45 connection
Shopfloor programming ToPs 100 lite
Safety:
Multi-beam light barriers
completely encapsulated and purged beam delivery
monitoring system
safety cabin
Automation:
LoadMaster
