GRAZIANO
08061
CNC Heidenhain
WORKING RANGE:
Max swing mm 550
Max turning diameter mm 400
Max diameter over slide mm 345
Distance centre mm 1000
Longitudinal Z axis mm 950
Cross X axis mm 300
Max load betweem centre Kg 350
SPINDLE:
Taper ASA 8''
Spe...
TACCHELLA
07404
Grinding lenght 600 mm
Max grinding diameter mm 255
TABLE:
Max automatic stroke mm 600
Min. automatic stroke 4 mm
Max inclination of the drill axis on the horizontal plane 10 degrees
GRINDING WHEELHEAD:
Wheel dimensions 457x76x127 mm
...
The compact, economical MITEE-BITE Uniforce® Clamp enables you to fixture more parts on the machine table. The specially designed steel wedge spreads the clamping force uniformly on both sides of the 7075-T6 aluminum channel. This form of Uniforce i...
