TOS VARNSDORF
07741
CNC HEIDENHAIN 416
Axis X mm 3500
Axis Y mm 1250
Axis Z (vertical) mm 2500
Axis W quill mm 800
Quill diameter mm 130
Table size mm 2200x1800
Loading Kg 12.000
Spindle Taper ISO 50
Spindle motor power Kw 37
Maximum orque Nm 3379
Sp...
PBR
10006
Height of centers mm 450
Max turning diameter on the bed mm 930
Max turning diameter on the cross carriage mm 600
Max turning diameter on the recess mm 1220
Bench width mm 630
Distance between centers mm 4000
Spindle attachment nose ASA 11'...
