MAZAK
09379
AXIS Y
SPINDLE/SUB-SPINDLE
LIVE TOOLS
CNC Mazatrol Fusion 640 MT
CAPACITY:
Max swing diameter mm 610
Max working diameter mm 610
Max working length mm 1552
Bar passaging mm 77
STROKES:
X-axis strokes mm 580
Y-axis strokes mm 230
Z axis st...
For clamping workpieces that must not be damaged. The clamping surface is grooved and not ribbed. This results in reducing the potential for marking components. The stepped jaw is hardened approx. 0.2 mm deep. The accuracy of the surface with respect...
Table size 457 x 153mm. Longitudinal travel of table 483mm. Total cross traverse of table 168mm. Traverse speed range per min 1.5 – 18m. Table traverse per revolution of handwheel 60mm. Grinding wheel size (standard) 180 x 13 x 31mm. 75mm bore. Gri...
DC52 Round Smooth Collet have the same accuracy specification as spring collets whilst maintaining a gripping range of +/- 0.5mm.
Supplied with either smooth or serrated gripping surface. DC52 Round Smooth Collet are ideal for aggressive first ope...
