One piece 30° slant bed with box guides
Large swing diameter 600mm
Z-axis travel 610mm (S26/60) or 1100mm (S26/110)
10” Power chuck
High thrust force 1441 Nm
High rapid feed 18/24 m/min (X/Z)
Available with C-axis & BMT – 65 Live tooling One pie...
ANSELMI
10098
Height of centers mm 180
Distance between centers mm 1500
Max turning diameter mm 390
Gap width mm 200
Bed width mm 320
Spindle bore mm 50
Spindle nose CAM-LOCK 6''
Quill tailstock Morse n.4
Spindle speed n.12 / rpm 37-1800
Motor HP 5.5...
