SpecificationsMotion Package:Travel method: Stationary table X,Y and Z axis movement for cutting headControl method: X,Y and Z simultaneous 3-Axis controlDrive motors: Fanuc AC Servo motorsMaximum sheet size (X,Y): 120" x 60"Maximum axis travel (X,Y,...
ALPIN
09828
WORKING CAPACITY:
Center height 180 mm
Turning diameter on the bed 360 mm
Distance between centers 1000 mm
SPINDLE:
Spindle nose CAMLOCK 6
Spindle bore 52 mm
HEAD:
No. speed 18
Spindle revolutions rpm 27-1650
THREAD:
Metric thread range
W...
