Code: COL005Height of Centres: 167mmBed Length Between Centre: 635 / 1000mmSwing over Bed: 330mmSwing in Gap: 480mmSwing over Cross Slide: 210mmSpindle Bore: 40mmSpindle Nose mounting: D1-4 CamlockMorse Taper in Nose Bush: No. 3 MTNumber of speed ran...
ZPS
08878
CNC HEIDENHAIN iTNC 530
TABLE:
Table dimensions mm 1800x780
T-slots number 5
T-slots distance mm 160
Max load Kg 2500
WORKING ARES:
Axis X stroke mm 1650
Axis Y stroke mm 810
Axis Z stroke mm 810
DISTANCE:
Spindle front to bed mm 110-920
S...
Swing over bed dia 650mm. Standard turning dia 234mm. Maximum turning dia 260mm. Swing over carriage dia 365mm. Distance Between centres 520mm. Bar capacity 52mm. Travels X/Z 50 + 130/400 mm. Rapid feed – X/Z axis m/min 30/30. Feed motor X/Z axis k...
