Spindle -
Max Distance spindle of table - 420mm
Max Distance spindle to column- 705mm
Min Distance spindle to column - 145mm
Quill Traverse - 150mm
Main Spindle taper - ISO 40
Variable speed head speed range - 60 - 4000rpm
Number of feeds...
Ground surfaces provide accurate positioning inside of t-slot. These nuts are manufactured from S45C(JIS) / CK45(DIN) heat treated to HRC 30-35 and have a black oxide surface finish.
– Variable speeds – Coolant equipment – Rear guard over the entire length of the machine – Square tool post – Threading Clock – Fixed centre and reduction sleeve – Leveling feeds – Protection of...
Maximum workpiece dia. 500mm. Maximum workpiece height 350mm. X/Y/Z travels 350mm/550mm/510mm. A Axis (table tilt) -120° / + 30°. C Axis (table rotation) indexing ) 0.0001° rotation 360°. Min/Max distance from spindle nose to table top (table hor...
