LTF
09842
Max drilling capacity diameter mm 16
Spindle taper CM2
Quill stroke mm 80
Spindle speed rpm 190-2800
Column diameter mm 80
Worktable dimensions mm 300x300
T-slot size mm 14
Base dimensions mm 450x310
Power supply 230V - 50Hz
Motor power kW ...
Spindle dia. 80 mm. Spindle taper 5MT. Table Size 1410 mm x 1250 mm. Table Longitudinal Traverse (Y) 2000 mm. Table Cross Traverse (X) 1250 mm. Head Stock Vertical Traverse (Z) 1150 mm. Spindle travel 710mm. Table Swivels 360 degrees. Facing Head Dia...
With the use of seal kits leaks from the front of back of the cylinder can be stopped. The replacement of the seals can either be done in house or can be sent to !st Machine Tool Accessories for replacement by one of our technicians.
